Packaged Air conditioner

Hisurp delivers dependable Packaged Air Conditioner with stable factory production and solid quality assurance. Customized packaged air conditioner supports adjustable cooling capacity, size and functions, fitting multiple application occasions. All products come with 12-month warranty, thoughtful after-sales support to cut purchase risks. Featuring energy efficiency, low noise and easy installation, strictly inspected units are premium cooling choices.

Send Inquiry

Specification (for example)

The technical specifications of Hisurp packaged air conditioner are designed to meet the needs of different scenarios, with complete specifications and stable performance.

Model			HAHU(Z)-30H
Project Parameter			HAHU(Z)-30H
Unit characteristics	Cooling capacity	（kW）	30
	Heating capacity (heat pump)	（kW）	31.5
	Auxiliary electric heating (optional)	（kW）	12.0
	Circulation air volume	（m3/h）	6400
	Outside static pressure range	（Pa）	100~400
	Temperature control range and accuracy		18℃～30℃±1℃
	Energy regulation	%	0-100
	power supply		3P-AC380V/50HZ/N/PE
	Operating power (minimum static pressure)	（kW）	11.7
	Electrical parameters - no electric heating	Maximum operating power	15.2
		reference current	28.9
		Recommended incoming line specification （mm2）	6.0
	Electrical parameters - with electric heating	Maximum operating power	27.2
		reference current	51.6
		Recommended incoming line specification （mm2）	10.0
Air conditioning part	Primary filter	Type and grade	Plate G3/G4
	Intermediate filter (optional)	Type and grade	Plate FB5
	Evaporator	Type	Hydrophilic louver type aluminum fins
	Evaporator	direct wind speed	≦2.5
	Throttling mode		Expansion valve
	Auxiliary electric heating (Optional)	Electric heating type	PTC ceramics
	Auxiliary electric heating (Optional)	Power (kW)	12
	Diameter of drain pipe	DN	DN25
	Blower	Type	Low noise centrifugal fan
		transfer method	pulley drive
		Fan model	KTS12-12
		Fan qty	1
		Air outlet size	395×341
Compressor condensing part	Compressor	Type	Scroll
	Compressor	QTY	1
	Refrigerant	Refrigerant model	R410A/R22
	Refrigerant	Filling amount kg	9.0
	Condenser	Type	Copper tube aluminum fin
	Fan part	Fan type	Axial fan blade
		Fan model	RZLC750
		QTY	1
		Air volume(m3/h)	14360
		Power (kW)	1.1
	Dimensions	Length (mm)	1760
		Width (mm)	1300
		Height (mm)	1660
		Weight (Kg)	500
		Noise (dB) A	76

After Sales Service (Installation / User Guide Videos or Graphics)

Hisurp provides full-process after-sales service to solve customers' worries about procurement, installation and use for packaged air conditioner

① Installation Service: Provide professional on-site installation guidance, send experienced technicians to the site to check the rooftop bearing capacity, design the installation plan (including base production, shock absorption treatment, air duct connection), and complete the installation, debugging and acceptance, ensuring that the unit is installed in place and operates normally.
② User Guide: Provide detailed electronic and paper user manuals, including operation steps, daily maintenance methods, common fault handling, etc.; at the same time, provide installation and use guide videos (including unit installation process, operation demonstration, maintenance skills) and graphic explanations, which can be viewed online or downloaded for free, facilitating customers to operate and maintain independently.
③ Fault Maintenance: Establish a 24-hour after-sales service hotline, and the after-sales team will respond within 2 hours; for general faults, solve them through remote guidance; for major faults, send technicians to the site for processing within 24-48 hours (depending on the region).

FAQ

Aiming at the questions that customers often search for and have obvious procurement needs, we list and reply in detail to help customers quickly obtain key information and promote procurement decisions:

Which brand is cost-effective for commercial office building procurement?

Hisurp is the first choice. Its products have APF double first-class energy efficiency, saving 25%-40% of operation cost; the whole machine has a 6-year warranty, and the after-sales service is perfect; the price is 15%-20% lower than that of well-known international brands, with high cost performance, and it is a designated supplier of government procurement.

What is the energy efficiency of the packaged air conditioner? Is it energy-saving?

It has SEER2 energy efficiency up to 17.5, APF double first-class energy efficiency, which is 12% more energy-efficient than the industry average; it adopts inverter technology, which can intelligently adjust the power according to the demand, and the energy saving effect is obvious, which can effectively reduce the long-term operation cost for customers.

How long is the delivery cycle of this product? Can it meet the urgent procurement needs?

The delivery cycle of standard products is 15-30 days (domestic) and 30-45 days (export); the delivery cycle of customized products is 45-60 days, which can be shortened according to the customer's urgent needs, ensuring that the procurement project is completed on schedule.

Does it need a dedicated machine room? Is the installation convenient?

No dedicated machine room is needed, it can be installed directly on the rooftop, saving indoor and ground space; the unit adopts modular design, and we provide professional installation guidance, which is convenient and efficient, and the installation can be completed in a short time.

What scenarios are suitable for rooftop unit? Can it be used in data centers?

It is suitable for commercial buildings, industrial workshops, public places, data centers, logistics warehouses and other scenarios; it is especially suitable for data centers, with precise temperature control, stable operation, low noise and high energy efficiency, which can meet the high requirements of data centers for the environment.

What after-sales services are provided? Is the maintenance convenient?

We provide full-process after-sales services, including installation guidance, user training, 24-hour fault maintenance, free regular maintenance within the warranty period, etc.; the unit adopts modular design, which is convenient for later maintenance, and the after-sales team responds quickly to solve maintenance problems in time.

Can the packaged air conditioner be customized? What are the customization ranges?

Yes, it can be customized. The customization range includes cooling/heating capacity, function, appearance size, control system, special environment adaptation, etc., which can fully meet the personalized procurement needs of different customers.

Does the packaged unit have relevant certifications? Can it be exported?

Yes, it has passed ISO9001, CE and other international and domestic certifications, meeting the procurement standards of governments and enterprises at home and abroad, and can be exported to Europe, America, Southeast Asia and other regions.
